Before you start

• Download required files from here.
• Place wxWidgets and RapidSVN source files into the previous 'prj' folder.

1. wxWidgets

• Open Visual Studio Solution file 'wxWidgets/build/msw/wx_vc15.sln'.
• On the toolbar, choose Release from the Solution Configurations list box.

• Build solution.

2. RapidSVN

• Open Visual Studio Solution file 'RapidSVN/build/vc2005/rapidsvn.sln'.
• On the toolbar, choose Unicode Release from the Solution Configurations list box.

• Select librapidsvn project and open project properties.
• C++ -> Preprocessor -> Preprocessor Definitions : Remove snprintf=_snprintf;
• Repeat for libsvncpp and rapidsvn project.
• Select rapidsvn project and open project properties.
• Linker -> Input -> Additional Dependencies :
  Replace wxbase30u.lib;wxmsw30u_core.lib;wxmsw30u_adv.lib; with wxbase31u.lib;wxmsw31u_core.lib;wxmsw31u_adv.lib;
• Linker -> General -> Additional Library Directories :
  Replace $(SUBVERSION)/lib/apr;$(SUBVERSION)/lib/apr-util;$(SUBVERSION)/lib/apr-iconv;$(SUBVERSION);
  with $(SUBVERSION)/../apr/Release;$(SUBVERSION)/../apr-util/Release;$(SUBVERSION)/../apr-iconv/Release;$(SUBVERSION)/Release/build/win32;
• Find '*.lib' files under svn/Release/subversion and move to svn/Release/build/win32.
• Copy apr-util/xml/expat/lib/LibR/libexpat.lib to svn/Release/build/win32.
• View -> Other Windows -> Property Manager
• Select librapidsvn, libsvncpp, rapidsvn and right click -> Add New Project Property Sheet... -> Add
• Expand 'librapidsvn' tree view -> Unicode Release | Win32 -> PropertySheet
• User Macros -> Add Macro
• Name : WX
• Value : ..\..\..\..\wxWidgets
• User Macros -> Add Macro
• Name : SUBVERSION
• Value : ..\..\..\..\svn
• C++ -> General -> Additional Include Directories :
  Set to $(SUBVERSION)/subversion/include;$(SUBVERSION)/../apr/include;$(SUBVERSION)/../apr-util/include
• Build rapidsvn project.

Before you start

• Download required files from here.
• Create 'prj' folder for workplace and place files as below

1. zlib

• Open Visual Studio Solution file 'zlib/contrib/vstudio/vc14/zlibvc.sln'.
• On the toolbar, choose ReleaseWithoutAsm from the Solution Configurations list box.
  (Asm version does not work correctly.)
• Select zlibstat project and open project properties (Below is needed to work with subversion.)
• C++ -> Preprocessor -> Preprocessor Definitions : Remove ZLIB_WINAPI;
• C++ -> Code Generation -> Runtime Library : Set to Multi-threaded DLL (/MD)
• Build zlibstat project. This will create 'zlibstat.lib'
• Move 'zlibstat.lib' from 'zlib/contrib/vstudio/vc14/x86/ZlibStatReleaseWithoutAsm' to 'zlib/' for later use.



2. expat

• Extract 'expat' folder in source to 'apr-util/xml/expat/'
• Open 'apr-util/xml/expat/expat.sln'.
• On the toolbar, choose Release from the Solution Configurations list box.
• Select expat project and open project properties
• General -> Windows SDK Version : Set to <inherit from parent or project defaults> or Installed SDK version
• C++ -> Code Generation -> Runtime Library : Set to Multi-threaded DLL (/MD)
• Linker -> General -> Output File : Set to .\LibR\libexpat.dll
• Linker -> Advanced -> Import Library : Set to .\LibR\libexpat.lib
• Build expat project. This will create 'libexpat.dll' and libexpat.lib'

3. apr, apr-util, apr-iconv

• Open 'apr-util/aprutil.dsw'.
• On the toolbar, choose Release from the Solution Configurations list box.
• View -> Other Windows -> Property Manager
• Right click libaprutil -> Add New Project Property Sheet... -> Add
• Expand 'libaprutil' tree view -> Release | Win32 -> PropertySheet
• User Macros -> Add Macro
• Name : XML_PARSER
• Value : .\xml\expat\lib\LibR\libexpat
• Build libapr and libaprutil project

4. openssl

• Open 'Developer command prompt for vs2017'.
• Go to 'prj/serf/openssl' (In my case, Z:\prj\serf\openssl)

  cd prj\serf\openssl
• Add nasm folder to path

  PATH=%PATH%;Z:\prj\serf\nasm

• Modify 'openssl/Configurations/10-main.conf'


  (Line 1299) "/MT /Zl"
           =>  "/MD /Zl"

  (Line 1312) "/MT"
           =>  "/MD"

• Configure


  perl Configure zlib --with-zlib-include=../../zlib --with-zlib-lib=../../zlib/zlibstat.lib no-shared enable-capieng VC-WIN32
• Build

  nmake

• Move 'libcrypto.lib', 'libssl.lib' from 'serf/openssl' to 'serf/openssl/lib/' for later use.

4. serf

• Open 'Developer command prompt for vs2017'.
• Go to 'prj/serf/serf' (In my case, Z:\prj\serf\serf)

  cd prj\serf\serf

• Modify 'serf/SConstruct'


  (Line 143) allowed_values=('14.0', '12.0',
           => allowed_values=('14.1', '14.0', '12.0',

  (Line 329) 'zlib.lib'
           => 'zlibstat.lib'

  (Line 338) ['libeay32.lib', 'ssleay32.lib']
           => ['libcrypto.lib', 'libssl.lib']

  (Line 346) '$OPENSSL/inc32'
           => '$OPENSSL/include'

  (Line 347) '$OPENSSL/out32dll'
           => '$OPENSSL/lib'

• Configure & Build


  ..\scons\scons.py APR=../../apr APU=../../apr-util OPENSSL=../openssl/ ZLIB=../../zlib LINKFLAGS=/SAFESEH MSVC_VERSION=14.1

5. Subversion

• Open 'Developer command prompt for vs2017'.
• Go to 'prj/svn' (In my case, Z:\prj\svn)

  cd prj\svn
• Add gettext folder to path

  PATH=%PATH%;Z:\prj\gettext\bin

• Modify 'svn/build.cfg'. Add following line in [libsvn_ra_serf] section


  msvc-libs = Crypt32.lib

• Modify 'svn-win32-libintl/inc/libintl.h'. Add following line at the top of the file


  #define LIBINTL_VERSION 0x00000e01
• Copy 'prj/svn-win32-libintl/' to 'prj/svn/build/win32' (Subversion's build script cannot find this library correctly)
• Configure

  gen-make.py --vsnet-version=2017 --with-apr=..\apr --with-apr-util=..\apr-util --with-apr-iconv=..\apr-iconv --with-zlib=..\zlib --with-sql=..\sqlite --with-libintl=..\svn-win32-libintl --with-serf=../serf/serf --with-openssl=../serf/openssl --with-static-openssl

• Build


  msbuild subversion_vcnet.sln /t:__MORE__ /p:Configuration=Release
